Configuration Level
Configurable
Configurable Online
CPU
Cores up to
64
CPU Manufacturer
AMD
Socket
AMD EPYC (SP3)
# CPU Sockets
1
Supported Processors
AMD EPYC Rome 7002 Series Processor
TDP
225 W
Drive Bays
Hot swap 3.5" Drive Bays
3 Bays
Expansion Slots
M.2
4 PCI-E 4.0/SATA x4, Form Factor: 2280, 22110, 2260, 2242 , Key: M-key
PCI-e
2 PCI-E 4.0 (x16) Low-profile slots, 1 SIOM Card Support (must bundle with network card)
General
Dimensions
17.25" (438mm) Width, 3.47" (88mm) Height, 30.5" (774mm) Depth
Manufacturer
Supermicro
Motherboard Model
H12
# of Nodes
4
Product Model
AS-2014TP-HTR
Chassis Format
Rack Form Factor
2U Rackmount
Drives
Total Drives Supported
12
Input / Output
DOM
2 SuperDOM
LAN
Must be bundled with a SIOM card, 1 IPMI
SATA Ports
3 SATA3
USB
2 USB 3.0 ports (rear), 1 USB 2.0 port (Type A)
Video Output
1 VGA
Management
IPMI
Yes
Memory
DIMM Type
RDIMM
DIMM Slots
8
ECC Supported
Yes
Max Memory Size
2000 GB
Max Memory Speed
3200 MHz
Memory Type
DDR4
On-Board Devices
Chipset
System on Chip
Graphics
ASPEED AST2500 BMC
Onboard IPMI
Support for Intelligent Platform Management Interface v.2.0
Network Controllers
1 PCI-E 4.0 x16 SIOM LAN Networking Slot for flexible networking (Must bundle with at least one SIOM network card)
SATA Controller
SATA3 (6Gbps) via AMD EPYC
Operating Environment
Operating Temperature
10°C ~ 30°C (50°F ~ 85°F)
Power Supply
Output
2000 W
80 Plus
Titanium
Redundant
Yes
CPU
AMD EPYC 7371 - 16-Core 3.10GHz 64MB FCLGA4094 200W
13 334 DKK
PS7371BDVGPAF
Stock: 0
Memory
12 912 DKK
